With these unique Led Street lighting for tunnel or a road, where lighting is on for extended periods, the system’s energy efficiency results in cost savings as high as 75% in the medium term. Similarly, in a sports complex or a manufacturing facility, which can require intensive lighting, the quality/ consumption ratio delivers immediate advantages.

ELECTRICAL SPECIFICATIONS
Voltage Frequency Electrical safety class Power supply efficienty
MECHANICAL FEATURES
Body Paint Glass External screws Total weight Ingress protection Impact resistance Wind exposed surface
OPTICAL FEATURES
Total reflection patent LED Photobiological safety
ELECTRICAL SPECIFICATIONS
220 ÷ 240 V ac 50 - 60 Hz Classe II 90%
MECHANICAL FEATURES
Die-cast alumininium EN 46100 Resistant to 1000 hours in salt spray Extra clear, 4-mm thick A2 stainless steel 9,5 kg IP 66 IK07 - 2j 0,159
OPTICAL FEATURES
1395290 CREEX XT-E (optics A)
PHILIPS LUMILEDS LUXEON M (optics B)
Exempt group
Model n. LED LED flux lm@4000K Power W
30 watt 16 2181 33W
40 watt 22 2965 45W
50 watt 28 3755 56W
60 watt 32 4261 64W
80 watt 40 5264 90W
120 watt 64 8220 125W
30 watt 4 2660 30W
45 watt 6 3990 45W
60 watt 8 5320 60W
75 watt 10 6650 75W
90 watt 12 7980 90W
120 watt 16 10641 120W
