• COMPLETE LED PERMANENT solution for tunnel lighting
  • Eventually associated with the TunnelLed TESEO for the Reinforcement solution
  • System International patent (2008) for total light emission by re ectors
  • Visual Confort and Uniform lighting without glare
  • Safety
  • Autodimming or total light output management
  • 120 000 hours
  • Running temperatures:
    -20/+55°C from 85 to 105W models
    -20/+60°C from 45 to 65W models
  • Made 100% in Italy and western of Europe
  • 5 Years warranty
ELECTRICAL SPECIFICATIONS
Voltage Frequency Electrical safety class Power supply efficienty Integrated Driver Flux control system Certifications
MECHANICAL FEATURES
Body Paint Glass External screws Total weight Ingress protection Impact resistance Wind exposed surface
OPTICAL FEATURES
Total reflection patent LED Photobiological safety
ELECTRICAL SPECIFICATIONS
220 ÷ 240 V ac 50 - 60 Hz Classe II 92,5% 1-10V or Dali for external Control Power line communication CE - RoHS - ENEC
MECHANICAL FEATURES
Die-cast aluminium EN 46100 Resistant to 1000 hours in salt spray Tempered extra clear, 4-mm thick A2 stainless steel 10,2 kg IP 66 IK08 - 5j 0,175
OPTICAL FEATURES
1395290 PHILIPS LUMILEDS LUXEON M
(optics B)
Exempt group
Model n. LED Luminaire flux lm@5700K Luminaire flux lm@6000K CRI Power W Efficacy lm/W
45 watt 20 4412 4510 70 45 98/100
65 watt 30 6601 6749 70 67 98/101
85 watt 40 8780 8976 70 88 100/102
105 watt 50 10948 11193 70 110 100/102
